Computer-Aided Design

Our engineering team can take your existing CAD files, from Revit, Advanced Steel, Civil 3D, Plant 3D, Auto Desk MEP, or Leica Cyclone and finalize them for a variety of fabrication processes. We can also scan nearly any object for further CAD modification.

Our fabrication skills are widely varied for a wide variety of projects. We can fabricate anything, and we also have water jet cutting tools that integrate perfectly with our design software for more exotic shapes, cuts and bevels.

We do all of our drafting and engineering design work from our home offices at Midwestern Millwright in Fort Morgan, Colorado. Click here for our main website.

Design

We have over 60 years of experience bringing your ideas into existence. Because of this, our expert computer draftsmen can help you avoid the pitfalls in industrial design. We have a Canon imagePROGRAF iPF785 MFP M40 36″ printer/scanner capable of scanning documents up to 36″ x 590″ and print large scale blueprints. We also have a Jumbo Tracer Digitizing System which can quickly and easily trace any outline, template, object, or part and create a DXF file for use by any CNC, CAD or cutting software and machine.

Let’s Talk

Call: (970) 747-4040

Use the form below or visit our office in Fort Morgan Colorado. We’re in the Midwestern Millwright complex.

115 Main Street

Fort Morgan, CO 80701

We’re open Monday – Friday, 8 a.m. – 5:30 p.m. Mountain
